Seagate 6TB SURVEILLANCE

Performance

Interface

SATA 6.0Gb/s

Capacity

6TB

RPM

5900 RPM

Cache

128MB

Features

The industry’s first surveillance-optimized hard drive platform with capacities up to 6TB improves video streaming, drive performance and data integrity in surveillance applications.

Seventh-generation Seagate surveillance drive is tuned for high write-cycle workloads typical in video surveillance storage systems.

The Surveillance HDD supports higher-resolution cameras and up to 16 drives per system, with up to 32 cameras per drive.

Reliably performs in multi-drive systems with RAID support from RV sensors.

24 x 7 operational capabilities while maintaining high MTBF of 1M hours.

Options for a current-limited startup of less than 2A supports the use of embedded system power supplies.

Low power consumption options support always-on surveillance systems.

Never miss a frame with quick time-to-ready.

Idle3 spin control features enable power-on in standby mode or drive spin-down to conserve power and improve reliability during archival periods.

Best-Fit Applications: NVR, Embedded SDVR, Hybrid SDVR, Surveillance DVR.

Dimensions

Form Factor

3.5″

Height (maximum)

26.11mm

Width (maximum)

101.60mm

Length (maximum)

147.00mm
